SPECIFICATION:
1.  VOLTAGE RATING: 24V &5A;
2.  CONTACT RESISTANCE :30Ω (MAX);
3.  INSULATION RESISTANCE :100MΩ MIN, DC250V;
4.  OPERATION TEMPERATURE: -25°C~90°C;
5.  WITHSTAND VOLTAGE:500VAC;
6.  INSERTION FORCE :30Kgf (MAX);
7.  EXTRACTION FORCE :0.3Kgf (MIN);
8.  LIFE TESTING:5000 CYCLES;
9.  SOLDERING FROCES:PARTS WILL WITHSTAND 260;
10.  EIAJ RC-53220A COMPLANT;
11.  ROHS 6/6 COMPLIANT.
